Description
Features
- Compatible with current Reliable Scale Weight Indicators
- Six digit super bright LED display (RD-06-0225, RD-06-0400) or backlight LCD display (RD-06-0100) is easy to read in sunlight or darkness
- lb, kg, Center zero, Motion, Alarm and Net annunciators
- Designed for mobile or stationary applications
- Ruggedly built and designed for agricultural and industrial applications
Specifications
| RC-06-0100 | RD-06-0100 | RD-06-0225 | RD-06-0400 | |
| Display | 1.00″, 6 digit LCD w/ LED backlight |
1.00″, 6 digit LCD w/ LED backlight |
2.25″, 6 digit LED* | 4″, 6 digit LED* |
| Communication Interface | RS-232 or optionally RS-485 or Bluetooth | RS-232 or optionally RS-485 or Bluetooth | ||
| Supply Voltage | 12 to 24 VDC | 12 to 24 VDC | ||
| Supply Current | 75mA @ 12VDC | 75mA @ 12VDC | 1.3 A @ 12VDC (all segments) | 3 A @ 12VDC (all segments) |
| Operating Temperature | -40F to 140F / -40C to 60C | |||
| Case Dimensions | 9″W x 4.75″H x 2″D / | 14.75″W x 4.75″H x 2″D / | 20.25″W x 6.63″H x 3.5″D / | |
| 23cm x 12cm x 5.1cm / 37cm x 12cm x 5cm / 51cm x 17cm x 9cm | 37.5cm x 12cm x 5.1cm | 51.4cm x 16.8cm x 8.9cm | ||
| Approximate Shipping Weight | ||||
| * Superbright LEDs are visible in direct sunlight. Specifications subject to change without notice. |
||||
Documents
RD Series Connector Pinout
