RH Series Heavy Duty Load Bars

Clear selection

Description

Features

  • Ruggedly built for use with large cattle chutes or hydraulically powered chutes
  • Easy to use electronics
  • Low profile design – only 3.4" high
  • Heavy duty armored cables
  • Enclosed tubing frame prevents rodent access


Applications

    • Hydraulic squeeze chutes
    • Bison & Cattle scales
    • Mobile platform weighing
    • Hopper and bin scales
    • Warehouse scale


Specifications

Model RHM-6K-30
Heavy Duty for Morand Industries Chutes
Model RH-6K-42
Heavy Duty General Purpose
Weight Capacity (pair)
12,000lb / 5,440kg
Accuracy
+/- 0.25% @ full load
Operating Temperature
-40F to 140F / -40C to 60C
Safe Overload
100%
Full Scale Output
0.6mV/V at full load
Maximum Excitation
15V ac or DC
Bridge Resistance
350 ohms nominal (each bar)
Overall Length
30" / 76.2cm 42" / 106.7cm
Approximate Shipping Weight (pair)
88 lb / 40 kg 110 lb / 50 kg
Specifications subject to change without notice.
