RB Series Load Bars

Clear

Description

Features

  • Ruggedly built for livestock handling
  • Easy to use electronics
  • Models available to suit many applications
  • Reliable weighing in harsh climates


Applications

  • Cattle squeeze chutes
  • Livestock pen and platform scales
  • Bale scale
  • Mobile platform weighing
  • Small mixer and batching scale
  • Hopper and bin scales
  • Warehouse scale


Specifications

Model RB18-1K
General Purpose
Model RB24-1K
General Purpose
Model RB-3K
General Purpose
Weight Capacity (pair)
2,000lb / 905kg 6,000lb / 2,720kg
Accuracy
+/- 0.25% @ full load
Operating Temperature
-40F to 140F / -40C to 60C
Safe Overload
100%
Full Scale Output
0.5mV/V at full load 0.6mV/V at full load
Maximum Excitation
15V ac or DC
Bridge Resistance
350 ohms nominal (each bar)
Overall Length
18″ / 46cm 24″ / 61cm 35.5″ / 90.2cm
Approximate Shipping Weight (pair)
18lb / 8.2kg 23lb / 10.5kg 55lb / 25kg

Specifications subject to change without notice.
